FT-80A / FT-100A / FT-120A Y-Blade Vertical Cutter Series | Vertical Flail Cutter for Vineyard and Orchard Rows
Model: FT-80A
FT-80A、FT-100A、FT-120A 提供三种切割宽度（800/1000/1200mm），配备 32-48 片 Y 型悬浮刀片永不堵塞。FT-80A 机身宽 980mm 是葡萄园专用机型，FT-120A 在开阔区域效率高达 9 亩/小时。
Key Features
Advanced technology for effortless lawn care
Y-Blade No-Clog Design
Y-type suspended swinging blades (32-48 pieces) cut and shred without clogging — even in wet, tall grass and light brush
Three Width Options
FT-80A (800mm/980mm body), FT-100A (1000mm/1170mm body), FT-120A (1200mm/1380mm body) — choose for your row spacing.
12-15HP Power
Kepu 192F (12HP) for 80A/100A, Kepu 195F (15HP) for 120A — purpose-built power for Y-blade cutting.
Full Remote + Self-Charging
24V electronic control with engine self-charging — no external power supply needed.
0-45° Slope
15-18cm wide tracked chassis operates on slopes up to 45° with sure-footed traction.
Stepless Speed Control
0-5km/h infinitely variable travel speed with manual cutting height adjustment 20-200mm.
Product Details
Comprehensive product description and features
Bottom Line Up Front
The FT-80A, FT-100A, and FT-120A offer Y-blade vertical cutting in three widths (800/1000/1200mm) with up to 48 suspended blades that never clog. The FT-80A at 980mm overall body width is the vineyard specialist — narrow enough for standard vine rows. The FT-120A at 1380mm maximizes productivity in open areas at up to 9 mu/hour.
Y-Blade Vertical Cutting for Professional Vegetation Management
The FT-80A / FT-100A / FT-120A series is Fengte's dedicated Y-blade vertical cutter line, designed for applications where traditional horizontal spinning blades clog or fail. The suspended Y-blade system swings freely, cutting and shredding vegetation without the wrapping and plugging issues common with conventional mower decks.
Vineyard-Optimized FT-80A
The FT-80A is the vineyard specialist. Its 980mm overall body width fits comfortably through standard vine row spacing (typically 2.0-2.5 meters between rows), while the 800mm cutting width with 32 Y-blades delivers efficient, clog-free mowing. Italian vineyard operators particularly favor this model for its combination of narrow profile and aggressive cutting ability.
Maximum Productivity FT-120A
At the other end of the spectrum, the FT-120A's 1200mm cutting width with 48 Y-blades achieves up to 9 mu (6000㎡) per hour — the highest productivity in the Y-blade series. Note that the 1380mm body width requires row spacing of at least 215cm, making it better suited for orchards and open areas rather than tight vine rows.
Never Clog, Never Stop
The Y-blade's suspended swinging design means each blade pivots independently when it encounters resistance — cutting through vegetation rather than wrapping around it. This is the key advantage over conventional horizontal blades in wet, tall, or mixed vegetation conditions.
Technical Specifications
Parameter | FT-80A (ZY-80A) | FT-100A (ZY-100A) | FT-120A (ZY-120A) |
|---|---|---|---|
Cutting Width | 800mm | 1000mm | 1200mm |
Cutting Height | 20-200mm manual | 20-200mm manual | 20-200mm manual |
Travel Speed | 0-5km/h | 0-5km/h | 0-5km/h |
Working Slope | 0-45° | 0-45° | 0-45° |
Blade Type | Y suspended | Y suspended | Y suspended |
Blade Count | 16 groups / 32 pcs | 20 groups / 40 pcs | 24 groups / 48 pcs |
Track Width | 15cm | 15cm | 18cm |
Control | Remote | Remote | Remote |
Starting | Electric | Electric | Electric |
Control Voltage | 24V | 24V | 24V |
Charging | Engine self-charging | Engine self-charging | Engine self-charging |
Engine | Kepu 192F (12HP) | Kepu 192F (12HP) | Kepu 195F (15HP) |
Efficiency | 0-6 mu/h | 0-7.5 mu/h | 0-9 mu/h |
Dimensions | 1560×980×820mm | 1560×1170×820mm | 1560×1380×820mm |
Net Weight | 338kg | 346kg | 356kg |
Packaging | 1620×1040×1030mm | 1620×1220×1030mm | 1620×1430×1030mm |
Gross Weight | 398kg | 415kg | 432kg |
Why Choose the FT-80A/100A/120A?
Choose the Y-blade series when clogging is your primary concern. The FT-80A (980mm body) is the vineyard specialist. For wider orchard work, the FT-550Y offers 550mm Y-blade cutting at just 137kg. For maximum slope capability, the FT-800D handles 65°.
Application Scenarios
Versatile performance across diverse environments
Vineyard Floors (FT-80A)
980mm body width fits vine rows; Y-blades shred vine cuttings without clogging — the vineyard specia
Orchard Vegetation (FT-100A)
1000mm width balances productivity and maneuverability for standard orchard row spacing.
Open Area Mowing (FT-120A)
1200mm width with 48 blades for maximum productivity on open ground — up to 9 mu/hour.
Roadside & Embankment
Y-blades handle the mixed vegetation typical of roadside and embankment areas without clogging.
Drainage Channels
Cut and shred vegetation in drainage channels where wet, tangled grass clogs conventional mowers.
Heavy Vegetation Areas
Y-blade system excels in tall, dense, or mixed vegetation that defeats standard horizontal blades.
Frequently Asked Questions
Everything you need to know about this product
The FT-80A is the vineyard specialist. Its 980mm overall body width fits standard vine row spacing (2.0-2.5m), while the FT-120A's 1380mm width would be too wide for many vineyard configurations.
Y-blades are Y-shaped blades that swing freely on a pivot. When they encounter resistance, they pivot and cut through rather than wrapping around vegetation. This prevents the clogging common with fix
The FT-80A and FT-100A use the Kepu 192F (12HP), while the FT-120A uses the Kepu 195F (15HP). These are purpose-built engines for the Y-blade cutting system.
FT-80A: 0-6 mu/h, FT-100A: 0-7.5 mu/h, FT-120A: 0-9 mu/h. The wider the cutting width, the higher the potential productivity.
Yes, cutting height is manually adjustable from 20mm to 200mm across all three models.
No. The 24V system is powered by engine self-charging — no external power supply or battery charging needed.
